Pin Box Female Male Header 0.80mm 1.00mm 1.27mm 1.50mm 2.00mm 2.54mm Single Double Row Straight Right Angle DIP SMT SMD Terminal Socket Connector

Package Size 35.00cm * 35.00cm * 35.00cm Package Gross Weight 30.000kg Pin Header Pitch=2.54mm Double Row Vertical SMT T;

Send inquiry

Basic Info.

Model NO.	WPH-8011-2XX-2GXB-XR
Certification	YUV, MSDS, CE, ISO 9001, RoHS, SGS, RoHS, Hf
Terminal Material	Copper
Interface Type	Pin Header
Material - Resin	Liquid Crystal Polymer
Number of Rows	1
Material - Plating Termination	Gold or Tin
Material - Plating Mating	Gold
Pitch - Mating Interface	2.50mm
Temperature Range - Operating	-55°c to +105°c
Packaging Type	Bag;Tube;Tray;Tape Reel
Orientation	Vertical
Termination Interface Style	Surface Mount
Durability (Mating Cycles Max)	500
Material - Metal	Copper Alloy
Flammability	UL94V-0
Breakaway	Yes
Circuits (Loaded)	1~40
Transport Package	Bag, Tube, Tape Reel
Trademark	winconn
Origin	China
Production Capacity	10000000

Packaging & Delivery

Package Size 35.00cm * 35.00cm * 35.00cm Package Gross Weight 30.000kg

Product Description

Pin Header Pitch=2.54mm Double Row Vertical SMT Type

P/N: WPH-8011-2XX-2GXB-XR

Product Parameters

1.Material:

HOUSING: THERMOPLASTIC,HIGH TEMP, 30% G/F

UL 94V-0, COLOR:BLACK.

CONTACT: BRASS.

2.FINISH:

CONTACT: AU PLATING OVER NI(50m" MIN.)

3.ELECTRICAL:

CONTACT RESISTANCE: 20 mΩ MAX.

INSULATION RESISTANCE: 1000MΩ Min.

DIELECTRIC WITHSTANDING VOLTAGE: 500V AC

CURRENT RATING: 3A

4.ENVIRONMENTAL:

OPERATING TEMPERATURE: -25°C TO +85°C
